Sena Bold Pergola
Curved pergola utilizing 102mm x 102mm (4”x4”) aluminum beams and 152 x 152 (6"x 6") columns. Components are pre-finished in premium polyester powder coating and mechanically fastened using stainless steel hardware. Designed as single or modular, in stand-alone or attached configurations Sena Bold is made to your specifications. Recommended 4267 (168”) minimum inside radius and maximum 5588 (220") outer span between columns .
Typical height: 2438 to 3000 (96” to 118”)
Typical Purlin Profiles - other sizes, styles and materials may be available
51x51
2x2
51x76
2x3
76x76
3x3
51x102
2x4
51x127
2x5
51x152
2x6
51x203
2x8
Cedar, Ipe and other species as specified. Custom sizing available
mm
in
in
mm
Aluminum
Wood (finished)
25x76
1x3
25x102
1x4
38x152
1.5x 5.5
38x140
1.5x3.5
38x89
1.5x6
89x89
3.5x3.5
Vertical Orientation Only
Power, Heat and Light
All sturdesign shade products can be manufactured to accommodate internal wiring for power supply. We can prepare our products to receive your specified accessories or we can supply market-approved accessories for USB CHARGING RECEPTACLES, INFRARED HEATING and LED LIGHTING (strip, marker, down lighting, spot lighting). See Accessories for more details and contact sturdesign for options and specifications.
Installation
Sturdesign's pre-fabricated manufacturing process simplifies onsite assembly and installation. We provide step by step instructions and we supply the tooling heads to engage any optional tamper proof stainless steel hardware. Typical bolt-down installation utilizes wedge anchors or embedded rods, custom site-specific solutions are available.
Optional Mounting Plate Cover
